Float Wire & Float Guide Wire : S.S.316 / Poly Propylene.Float : S.S.316 / S.S.304 / Poly Propylene.In vapour seal there is no sealing liquids so we get absolute vapour tightness.alkalies, dilute HNO3,NH3 Methanol,Banzene,Toluene, IPA etc.Vapours seals (Magnetic) for special applications like HCl,N2 purged tank, diluted.Mainly used for storage tanks of Oil, Fire / DM water Alkalies, Acids furnace Oils, Lube Oil, Vegetable Oil, Molasses, Glucose etc.Level is indicated by a pointer which moves on a 150 mm width aluminium powder coated scale.
WATER TANK DEPTH GAUGE FREE
A rope fitted with a float moves over a pair of dust free pulleys. A large self centred float follows the liquid level in this gauge.So that horizontal movement of the float is restricted. For more than 5 metre height of the tank we provide two guide wires firmly anchored to the tank bottom. This float connected to a pointer through Rope via a Sets of Pulleys, The pointer slides over a CM marked Board,Installed Parallel to the tank. In this level gauge, the float is design as per the specific gravity of the liquid, floating on the liquid levels. The Float is available in different material S.S.304 / S.S.316/P.P./Teflon etc. Float wire, Mountain Breakets indicator pulley pulley hosing scale, indicator etc. Nonetted parts are the one which do not come in contact with the liquid e.g. Float anchor plan float guide wire etc while. Wetted parts are those which come in contact with the liquid e.g. The whole unit consist of two types of parts. The Specific Gravity of the fluid should be more than 0.6(Free Flow) This level gauge wonks on the principle of buoyancy.
This gauge is also applicable to cone roof, float roof, floating roof, under grand tanks etc. “Flowtech” offer Float & Board Type Tank Level gauge (indicator) suitable for large non –pressurized liquid storage tanks / vessels.
